| Capacity kg(lb.)： | 1500 (3300) |
| Min. Fork Height mm(in.)： | 80 (3.1) |
| Max. Fork Height mm(in.)： | 200 (7.9) |
| Load Center mm(in.)： | 600 (23.6) |
| Wheelbase mm(in.)： | 1255 (49.4) |
| Overall Forks Width mm(in.)： | 560 (22) |
| Fork dimentions mm(in.)： | 1150×160×46 (45.3×6.3×1.8) |
| Inner Width between Forks mm(in.)： | 240 (9.4) |
| Front Wheel mm(in.)： | φ78×70 (φ3×2.8) |
| Driving Wheel mm(in.)： | 750W, φ210(φ8) |
| Wheels Material/Number (Front/Driving/Balance Wheel)： | Polyurethane,4/1/- |
| Overall Dimensions mm(in.)： | 1630×560×1252 (64.2×22×49.3) |
| Turning Radius mm(in.)： | 1460 (57.5) |
| Travel Speed(with/without load) (Km/h)： | 3.5/4.0 |
| Lift Speed(with/without load) (mm/s)： | 51/60 |
| Lowering Speed(with/without load) (mm/s)： | 59/52 |
| Max. Gradeability(with/without load) (%)： | 2/6 |
| Service brake： | Electromagetic |
| Drive motor (W)： | 650 |
| Lift motor (W/V)： | 800 |
| Battery (V/Ah), kg(lb.)： | 24/60 |
| Battery Charger (A/V)： | 15/24 |
| Net Weight kg(lb.)： | 237 (521.4) |
| Type： | Semi-Electric,Pedestrian,without platform |
