| Capacity kg(lb.)： | 1500 (3300) |
| Load Center mm(in.)： | 600 (23.6) |
| Max. Fork Height mm(in.)： | 2900 (114.2) |
| Overall Length mm(in.)： | 2020 (79.5) |
| Overall Width mm(in.)： | 850 (33.5) |
| Overall Height mm(in.)： | 1930 (76) |
| Max. Overall Height mm(in.)： | 3322 (130.8) |
| Min. Height of forks mm(in.)： | ≤90 (3.5) |
| Overall Width of Forks mm(in.)： | 560/680 (22/26.8) |
| Dimension of Fork mm(in.)： | 1150×160×56 (45.3×6.3×2.2) |
| WheelBase mm(in.)： | 1328 (52.3) |
| Ground Clearance mm(in.)： | ≥30 (1.2) |
| Min. Turnig Radius mm(in.)： | 1600 (63) |
| Min. Stacking Aisle mm(in.)： | ≥2500 (98.4) |
| Climb Gradient Loaded (%)： | 5 |
| Traveling Speed with/without load Km/h(Mph)： | 5/4 (3.1/2.5) |
| Lift Speed with/without load mm/s(in./s)： | 93/143 (3.7/5.6) |
| Lowering Speed with/without load mm/s(in./s)： | 94/120 (3.7/4.7) |
| Net Weight(no battery) kg(lb.)： | 890 (1958) |
| Battery Capacity/Voltage (Ah/V)： | 240/24 |
| Lift Motor (kw/V)： | 2.0/24(DC) |
| Travel Motor (kw/V)： | 1.5/17(AC) |
| Turning Motor (kw/V)： | 0.15/24(DC) |
| Front Wheel mm(in.)： | φ78×70 (φ3×2.8) |
| Balancing Wheel mm(in.)： | φ125×75 (φ5×3) |
| Driving Wheel mm(in.)： | φ230×80 (φ9×3.1) |
