| Type： | Electric (built in charger) |
| Capacity kg(lb.)： | 1000 (2200) |
| Max. Fork Height mm(in.)： | 800 (31.5) |
| Min. Fork Height mm(in.)： | 85±2 (3.3±0.1) |
| Fork Width mm(in.)： | 680 (26.8) |
| Fork Length mm(in.)： | 1190 (46.9) |
| Ground Clearance mm(in.)： | 20 (0.8) |
| Front Load Roller mm(in.)： | φ75×75 (φ3×3) |
| Steering Wheel mm(in.)： | φ180×50 (φ7×2) |
| Pump Strokes to Max. Height without/with Rated Load (times)： | - |
| Lifting Time, without/with Rated load (sec)： | 11/19 |
| Battery (Ah/V)： | 70/12 |
| Battery Charger： | Built-in 6A/12V |
| Net Weight (without Battery) kg(lb.)： | 164 (360.8) |
