    BSS/BSA SERIES
    ▲ Robust structure yet light weight.
    ▲ Made of stainless #304.(BSA is made of Aluminum)
    ▲ Two brakes increase safety.
    ▲ Stainless structure ideal for phar maceutical,food,beverage etc.
    ▲ Meet EN1750.
    Hu-LIFT NO. Model No. Capacity kg(lb.) Min. Height mm(in.) Max. Height mm(in.) Wheel Dia. mm(in.) Table Size mm(in.)
    1313101 BSS10 100 (220) 265 (10.4) 755 (29.7) φ100 (φ4) 700×450 (27.6×17.7)
    1313102 BSS20 200 (440) 330 (13) 910 (35.8) φ125 (φ5) 830×500 (32.7×19.7)
    1313103 BSS50 500 (1100) 442 (17.4) 1000 (39.4) φ150 (φ6) 1010×520 (39.8×20.5)
    1313104 BSA10 100 (220) 265 (10.4) 755 (29.7) φ100 (φ4) 700×450 (27.6×17.7)
